Your Professional Manure Spreader Supplier
IMETEC Intelligent Equipment (Shandong) Group Co., Ltd. is a national high-tech enterprise specializing in the production, R&D and export of intelligent equipment for dairy farm equipment.Our products cover from self-propelled full series of TMR feed mixer, leftover material collector, intelligent feed pusher, bedding spreader, manure spreader, and hay crusher, etc. 8 categories of more than 200 models, four categories of 57 models of products, has entered the national agricultural machinery subsidies to promote the catalog.
-
![Pull Manure Spreaders]()
Pull Manure SpreadersThe IMETEC solid pull manure spreaders delivers significant cost savings for farms by reducing reliance on chemical fertilizers, lowering equipment investment, and minimizing labor costs. By -
![Skid Steer Manure Spreader]()
Skid Steer Manure SpreaderThe Skid Steer Manure Spreader is a heavy-duty, high-performance attachment engineered for skid steer loaders. Designed to replace cumbersome tractor-towed units, this equipment leverages the agility -
![Little Manure Spreader]()
Little Manure SpreaderThe LITTLE MANURE SPREADER is a high-performance, tractor-trailed solution engineered for modern livestock operations and large-scale agriculture. This heavy-duty machine is designed to convert solid -
![Solid Cow Manure Spreader]()
Solid Cow Manure SpreaderThe IMETEC brand solid cow manure spreader adapts to diverse crop types—including grains, vegetables, fruits, and forage—with adjustable spreading width (10-14m) and material output. Whether -
![Big Solid Manure Spreader]()
Big Solid Manure SpreaderThe IMETEC big solid manure spreader’s dual vertical high-speed agitators excel at breaking down clumpy livestock manure, ensuring uniform spreading and optimal nutrient release. These agitators -
![Solid Manure Spreaders]()
Solid Manure SpreadersPowered by the tractor’s rear PTO (Power Take-Off), the IMETEC solid manure spreader integrates seamlessly with existing farm equipment, eliminating the need for separate power sources. This design -
![Liquid Cow Manure Spreader]()
Liquid Cow Manure SpreaderUpgrade your Liquid cow manure Spreader application with our tractor-powered tank spreader, a high-performance solution designed for modern agriculture. Using a powerful vacuum pump, it injects -
![Fertilizer Manure Spreader]()
Fertilizer Manure SpreaderThe liquid organic Fertilizer Manure Spreader is a modern, high-efficiency agricultural machine driven by a tractor. It employs a vacuum pump to deliver liquid fertilizer directly from the tank to -
![Big Liquid Manure Spreader]()
Big Liquid Manure SpreaderThis tractor-powered Big Liquid Fertilizer Spreader is a high-efficiency agricultural implement designed for precise soil application. Using a vacuum pump system, it directly transfers liquid organic -
![Liquid Fertilizer Spreader]()
Liquid Fertilizer SpreaderThis Liquid Fertilizer Spreader is a high-efficiency agricultural machine powered by a tractor. It uses a vacuum pump to directly inject liquid fertilizer from the tank into the soil, enabling -
![Mobile Manure Spreader]()
Mobile Manure SpreaderReplacing traditional mechanical transmission with a dual hydraulic propulsion system, the IMETEC solid fertilizer spreader offers stable, uniform material feeding. This advanced hydraulic design -
![Tractor Driven Manure Spreader]()
Tractor Driven Manure SpreaderIMETEC’s solid fertilizer tractor driven manure spreader delivers exceptional spreading uniformity with a coverage width of 10-14 meters, ensuring every inch of farmland receives consistent nutrient
Our Certifications
Comprehensively passed the IS09001:2015 international quality management system and the European Union CE certification, IMETEC trademark has passed the Madrid International Trademark Registration with the Ministry of Agriculture and Rural Affairs of Nanjing, Shandong Agricultural University, Shandong University, Shandong Agricultural Machinery Institute and other scientific research institutes, breakthroughs in foreign necks more than ten, currently has a total of 108 patents of invention.
Rich Experience
With more than 15 years of service experience, we will spare no effort to provide support in selecting equipment, customizing production lines, improving supply chain, and post-optimization etc.
Support Customization
Relying on our powerful flexible production line, we can give you the right to fully choose the mold,drive method, accessories upgrade, shell material, appearance color and Logo etc.
Competitive Prices
By buying directly from our factory, you avoid middleman costs and enjoy competitive pricing. We aim to provide high-quality machines at the best value, especially for bulk orders or long-term cooperation.
Manure Spreader Specifications
|
Model |
2FS-3 |
2FS-6 |
2FS-9 |
|
Volume capacity(m³) |
≥3 |
≥6 |
≥8 |
|
Maximum deadweight(kg) |
3000 |
6000 |
7200 |
|
Machine weight(KG) |
1600 |
2200 |
2450 |
|
Spreading width(M) |
6-14 |
6-14 |
6-14 |
|
Machine size (mm) L*W*H |
4100*2010*1900 |
4510*2200*2290 |
5500*2250*2480 |
|
Hopper size (mm) L*W*H |
2600*1795*1290 |
3130*2000*1795 |
4000*2000*1640 |
|
Fertilizing form |
Horizontal double discs are thrown backward |
||
|
Number of disc blades |
3 |
3 |
5 |
|
Maximum diameter of disk (mm) |
640 |
640 |
620 |
|
Traction length (mm) |
1210 |
1210 |
1235 |
|
Minimum height from ground (mm) |
380 |
380 |
370 |
|
Conveyor chain width (mm) |
405(double row) |
405(double row) |
990 |
|
Center distance of tire (mm) |
1700 |
1850 |
1850 |
|
Tires |
12.5/80-15.3 |
14-17.5 |
400/55-22.5-18PR |
|
Drive way |
PTO |
PTO |
PTO |
|
PTO speed(rpm) |
540 |
540 |
540 |
|
Work efficiency (m³/h ) |
≥10 |
≥10 |
≥10 |
|
Required tractor power(hp) |
50-70 |
60-80 |
80-140 |
|
Conveying control mode |
Hydraulic |
Hydraulic |
Hydraulic |
|
Hydraulic system pressure |
16Mpa |
16Mpa |
16Mpa |
|
Hydraulic system flow rate |
≥30LPM |
≥30LPM |
≥30LPM |
|
Driving speed (km/h) |
3-20 |
3-20 |
3-20 |
|
Working speed (km/h) |
≤10 |
≤10 |
≤10 |
|
40 HQ container |
4pcs(8pcs) |
3pcs |
2pcs+1pcs |
- High Efficiency: Optimized for maximum productivity in farm fertilizing tasks.
- Durable Design: Built to withstand harsh agricultural environments and heavy use.
- Wide Application: Suitable for various agricultural needs including manure spreading.
- Hydraulic Control: Easy and precise control over the spread width and speed.
- Broadcast Spreader: Efficiently distributes fertilizer across large areas.
- Large Capacity: Features a big hopper to reduce refilling times and improve working efficiency.
- Even Spreading: Ensures uniform distribution of fertilizer for better crop growth and yield.
- Easy Maintenance: Simple structure design for convenient daily cleaning and upkeep
Applications
Crop Field Fertilization: Applying nutrient-rich livestock manure to corn, soybean, and wheat fields to reduce synthetic fertilizer needs.
Pasture and Hay Field Maintenance: Distributing manure on pastureland to improve hay growth and increase phosphorus levels in low-testing soils.
Solid Manure Management: Using box spreaders or side-discharge spreaders for solid dairy, beef, or poultry waste.
Liquid Waste Application: Utilizing tank spreaders with splash plates or injectors for liquid hog manure to reduce odor and runoff.
Compost and Organic Amendment Spreading: Applying processed compost, biosolids, or lime to improve soil structure and fertility.
Small Farm/Equine Management: Employing smaller ground-driven spreaders pulled by ATVs or small tractors to manage manure on smaller horse or hobby farms.
